Combination pliers Industrial with DynamicJoint® and OptiGrip

with extra long cutting edge

Export PDF

Add to bookmarks

Remove from bookmarks

Order number	EAN										Netto
30826	4010995308261	180 mm	7"	3.4 mm	2.2 mm	1.8 mm	16	1.8 mm	-	273	€
30978	4010995309787	200 mm	8"	3.8 mm	2.5 mm	2 mm	17	2 mm	-	338	€
34307	4010995343071	180 mm	7"	3.4 mm	2.2 mm	1.8 mm	16	1.8 mm	x	296	€
34308	4010995343088	200 mm	8"	3.8 mm	2.5 mm	2 mm	17	2 mm	x	361	€

Overall length (mm)

Overall length (Inch)

Medium-hard wire (mm)

Hard wire (mm)

Hardened spring steel (mm)

Cutting force

Diameter max (mm)

Blister packed

Weight PU in grams

Series Z 01 0 02

Size specifications are always given in mm

Highlights

2in1: Cutting and gripping

DynamicJoint® - Innovative unique joint design

No twisting or slipping

Kind to hands and muscles

Product Description

Product description

A variety of pliers are essential for professional industrial jobs. The combination pliers with DynamicJoint® and OptiGrip made by Wiha combine the functions of several pliers and thus minimize the number of required tools. The pliers are used for gripping as well as cutting of soft and hard wires and cables. Thanks to the gripping zone for round and flat material, the combination pliers can be used for many tasks, and its extra long cutting edge makes it additionally suitable for flat and round cables. What is more, the innovative pliers joint with DynamicJoint® ensures that the hand force is optimally transferred to cutting surfaces, providing up to 20% greater cutting force. Another advantage is offered by our Optigrip – the newly designed gripping surface with "triple-point support" ensures optimal hold of the workpiece while working and eliminates any twisting or slipping. The ergonomically shaped plier handle ensures comfortable, fatigue-proof work. The cutting edges that are inductively hardened to approx. 64 HRC and the high-quality C 70 tool steel contribute to a long tool life.

Product dimensions

250 x 100 x 32 mm (LxWxD)

Standards

DIN ISO 5746.

Note

To benefit from this product for as long as possible, we recommend regularly applying a drop of oil after use.

Standard text

Wiha Werkzeuge GmbH is certified according to ISO 9001:2015, ISO 14001:2015 and ISO 50001:2018 and confirms that its products comply with internal regulations, operating instructions as well as applicable norms, standards and legal requirements and are subject to continuous process monitoring. The product complies with the requirements of Regulation (EU) 2017/821 on conflict minerals as well as the OECD Due Diligence Guidance, the General Product Safety Regulation (GPSR), Regulation (EC) No 1907/2008 (REACH), whereby the latest SVHC Candidate List is regularly reviewed and requirements are implemented, Directive 2011/65/EU (RoHS) including amendment (EU) 2015/863 as well as Regulation (EU) 2019/1021 on persistent organic pollutants (POP).

Application

General purpose pliers for gripping and holding as well as cutting soft and hard wires and cables.
